SUBMERSIBLE PUMP

JH-QYB-240 RED JE CKET SUBMERSIBLE TURBINE PUMP

Model JH-HQB75、JH-HQB150、JH-HQB200

Max flow rate 240L/min

Rotate speed 2850RPM、3420RPM
Voltage 220V/50Hz、230V/60Hz、380V/50Hz、
Current 9A
Power 0.75HP(0.5KW)、1.5HP(1.1KW)、2HP(1.5KW)
Inlet BSPF/NPT 1-1/2''
Outlet NPT 2''
  • Product Detail

JH-QYB-240 RED SUBMERSIBLE TURBINE TUMP


  • Best performance,long time service, lower noise
  • Easy to install and service.
  • Quick, simple and safe electrical connections
  • Manifold allows for vertical or horizontal discharge
  • Save time, lower service costs
  • Built with check valve, by pass valve, vacuum valve
  • For diesel, gasoline, kerosene, etc.
  • Vapor-free, suction head longer than suction pump
Rating pressure 0.3Mpa
EX-proof class 1P*6
fixation thread BSPF/NPT4''
Dimension 380*310*380mm
810*210*210mm
Net weight 55kg
Gross weight 58kg
Package 1pcs/2ctn
Ex-proof Class Ex db Sa IIB T4 Gb/Ga
