FUEL NOZZLE SERIES

JH-200 1-1/2''NPT HIGH QUALITY MANUAL NOZZLE

Inlet thread BSPF/NPT1-1/2"
Spout 38mm
Packing 10 pieces/carton
Net weight 23kg
Gross weight 24kg
Dimensions 350×350×520mm
  • Product Detail

JH-200 1-1/2''NPT HIGH QUALITY MANUAL NOZZLE

Matetial
Aluminum Alloy
Working pressure
0.2Mpa
Auto Shut-off sensibility
0.1 second
Inlet Thread
BSPF/NPT 1 1/2''
Spout Outlet Diameter
38mm
Flow Rate
0-200L/min

JH-200 automatic nozzles are made of aluminum alloy and designed with big flow rate,the max flow rate is up to 200L/min.If you need some big flow rate fuel nozzle for your fuel dispensing, then this product can perfectly meet your demand.

FEATURES & BENEFITS

  • For heavy-duty, high-flow truck, bus and home fuel delivery service.
  • Nozzle body material is aluminum alloy: light weight, more convenient to handle and easier to use.
  • It can be controlled by a hand to open/close and set 2 different flow speeds conveniently.
  • Automatically shuts-off the flow of fuel when vehicle tank is full.
