JH-120B AUTOMATIC FUEL NOZZLE FOR FUEL DISPENSER
- JH-120B Automatic Nozzles are designed specially for self-service pre-pay of card-lock system to help prevent gasoline spills.
- The JH-120B con not be opened untill the pumping system is pressurized and closes automatically when the pressure is removed.
- This means the JH-120B closed when placed back to the dispenser.
- Accurate flow control allow your customers to top off their tank to the exact amount they want,and it's easy to stop gasoline flow precisely.
FEATURES & BENEFITS
- One-piece spout-Innovation design eliminates possible leak points, is lighter in weight.
- "Accu-Stop" flow control-Allows your customers to top off their tanks to the exact amount they want, and easy to stop flow accurately.
- Flow Lock-Designed to shut-off automatically when the spout is tipped up, limiting spillage.
- Hold-open rack is available for full-service applications-the one-hand control means easy setting to flow rate for customer convenience.
- Blocker on lever guard- to help prevent the nozzle from being jammed into open position with a foreign object.
- Low reliable shut off- Specially designed to ensure proper shut-off as low as 3 gallons per minute.
- Exclusive two-stage lever assembly- provides a positive shut-off, even if held in wide open position by user.
- Suitable for diesel, kerosene, gasoline and gasoline with ethanol blends.
- 100% Factory Tested.
Main stem seals
Viton cased oil seal / Graphite with Teflon
Auto Shut-off sensibility
Spout Outlet Diameter
1 1/16" or 1 3/16''
0-60L/min or 0-120L/min
