JH-3 BREAKAWAY VALVE FOR VAPOR RECOVERY HOSE

Breakaway valve is installed on one side of fuel dispensing hose.Under the designed pull force, breakaway valve will separate to reduce expensive damage to the dispenser and piping system. And the breakaway valve will close automatically during separation, stopping the flow of fuel from both the dispenser and the separated hose.

Production Features

Material

Body Material	Aluminum
Seal Material	Viton
Main Spring	Stainless steel
Guide and poppet	POM
Protective Sleeve	PVC

Thread: BSP/NPT 3/4'' or 1''

Working pressure: 0.18 Mpa

100% factory tested
