OGM-50/80/100 CAST IRON OVAL GEAR FUEL FLOW METER

Size 2''(OGM-50);3''(OGM-80);4''(OGM-100)
Min flow rate 60L/min(OGM-50);140L/min(OGM-80);160L/min(OGM-100);
Max flow rate 300L/min(OGM-50);700L/min(OGM-80);1600L/min(OGM-100);
Accuracy ±0.2% or 0.5%
Repeatability ≤0.03%
Max pressure 1.8Mpa

Product Detail

OGM-50/80/100 CAST IRON OVAL GEAR FUEL FLOW METER

OGM-50/80/1 00 cast Iron oval gear meter has the ability to handle a wide range of fluid viscosities with exceptional levels of repeatability and durability,applying to the industry and commerce of petroleum, chemical, medicine, transportation, food, etc.

Benefits

Compact size, easy maintenance.
Easy to read and operate mechanical display.
Horizontal and vertical flexibility of installation options.
Low pressure drop.

Model	OGM-50	OGM-50	OGM-50
Size	2''	3''	4''
Min Flow Rate	60L/min	140L/min	160L/min
Max Flow Rate	300L/min	700L/min	1600L/min
Accuracy	±0.2% or 0.5%	±0.2% or 0.5%	±0.2% or 0.5%
Repeatability	≤0.03%	≤0.03%	≤0.03%
Max Pressure	1.8Mpa	1.8Mpa	1.8Mpa
