VAPOR RECOVERY SYSTEM STAGE Ⅱ

JH-VRQ-50 (ZVA)FUEL AUTO NOZZLE FOR GAS PUMP DISPENSER STATION

Model JH-VRQ3-50
Pressure resistance 5.3Bar

flow rate ≥38L/min(big);≥30L/min(small)

Inlet thread M34*1.5mm

non-pressure shut off Yes

Conductive resistance ≤4Ω

  • Product Detail

JH-VRQ-50 (ZVA)FUEL AUTO NOZZLE FOR GAS PUMP DISPENSER STATION

JH-VRQ-50 Oil Vapor Recovery Gun is an oil and gas recovery type refueling gun with beautiful appearance, light weight, stable performance, labor-saving firing and strong versatility. This refueling gun not only maintains the consistent advanced technology level abroad , and made a unique design and improvement according to the characteristics of the diversity of automobile fuel tanks in the Chinese market, and serve the domestic market with more professional and personalized products. It can be applied to centralized oil and gas recovery system and decentralized oil and gas recovery system.


  • The refueling gun is equipped with an air sealing cover, which can effectively improve the oil and gas recovery effect.
  • Built-in oil and gas recovery channel.
  • Standard component design, easy replacement of parts (barrel).
  • Applies to self-serve prepaid gas stations.
  • The coaxial 304 stainless steel barrel is used to make the refueling gun more durable, and it is designed with a shear groove (according to UL standard) to effectively protect the refueling machine.
  • The main valve is opened against the oil flow, which is more secure.
  • The gun adopts a pressureless self-sealing structure design, and the gun needs to be opened to work under the condition of oil pressure, which is safer and meets the UL842 standard.
  • Conform to safety and environmental protection requirements.
  • It is highly versatile and can be compatible with OPW, ZVA, HUSKY, Veeder-Root, Heineken and other international brand tankers, as well as all domestic tankers.
