JH-TFM 1.5INCH MINI DIGITAL TURBINE FLOW METER

Inlet&Outlet	BSPT1'' or 1 1/2''
Flow rate	5-50GPM(18.9-190LPM)
Accuracy	±1%
Repeatibility	±0.3%
Material	Aluminum alloy
Voltage	3V
Working temperature	-10℃~+60℃（14℉~140℉）
Weight	684g
Max pressure	20BAR

Features&Benefits

• Modular Design: Modular design makes it suitable for use with output modules, sensors and remote transmitters.
• High Accuracy: The measuring accuracy of this flow meter is ±1%, fit for most places.
• Digital: This flow meter can provide a intuitive clear reading, high reliability.

• Instantaneous and Cumulative Flow: High-definition displays show both instantaneous and cumulative flow,meet your different needs.
• Wide Application: The flow meter can be widely used to measure diesel, kerosene, gasoline, etc.
